Specifications
Parameters | Unit | AGNI 400 |
---|---|---|
Power voltage | V | 415 V ± 10% |
Phase | 3 | |
Supply Frequency | Hz | 50 |
Max. Output Current | A | 400 |
Duty Cycle | % | 60 % |
Efficiency | % | ≥ 85 % |
Power Factor | ≥ 0.93 | |
Insulation Class | H | |
Protection Class | IP23 | |
Machine Cooling Type | Forced Air Cooled | |
Current or Voltage Regulation Type | Stepless | |
Wire Feeder Type | Separate | |
Confirm To IS | IS 7931 [Part II] : 1975 | |
Weight | kg | 41.7 |
Wire Feeder Dimension (L x W x H) | MM | 520 x 190 x 330 |
Dimensions (L x W x H) | MM | 600 x 300 x 550 |
