Air Plasma Cutting (160 Amp.)

Salient Features :

  • High frequency with easy arc starting
  • Built with soft switch technology
  • Low power consumption, high performance inverter technology
  • High cutting speed
  • Stepless power control
  • User friendly, Easy to install
  • Less maintenance
SKU: VYAN 160

Specifications

Parameters Unit VYAN 160
Power voltage V 415 V ± 10%
Phase 3
Supply Frequency Hz 50
No-load voltage V 298
Min. Output Current A 30
Max. Output Current A 160
Duty Cycle % 60 %
Efficiency % ≥ 85 %
Power Factor ≥ 0.93
Insulation Class H
Protection Class IP23
Machine Cooling Type Forced Air Cooled
Current or Voltage Regulation Type Stepless
Confirm To IS IS 4804 [Part II] : 1968
Weight kg 40.5
Dimensions (L x W x H) MM 600 x 750 x 750

Scope & Applications

“VULCAN” Inverter air Plasma Cutting Machine. The machine is capable of cutting bath ferrous as well as non- ferrous metals. Inverter Air Plasma Cutting Machine is required for producing smooth nicks free cuts on metal workpieces in no time. It is widely utilized in construction, architectural, metal repair & fabrication, and automotive industries. This machine is highly appreciated for praducing fine cuts with high speed & minimal distortion.
